HYDRAULIC HOSE

PH704 SERIES

Applicable Standard : Polyhose proprietary hose

Construction

Inner tube  : Polyamide

Reinforcement : Single braid of synthetic fiber and single braid of stainless steel wire

Application : Medium pressure hydraulic Lines 120 to 210bar. Suitable for applications requiring chemical resistance to solvents and aggressive fluids. Due to low permeation value of polyamide, the hose is also suitable for industrial gases.



Category:

Description

Item
Code
Dash
Size
DN
ID

OD

OD
WP
BP
BR/r
W
inch mm inch mm psi bar psi bar inch mm g/m
PH704-03 -03 05 3/16 4.80 0.350 8.9 3045 210 12180 840 1.8 45 90
PH704-04 -04 06 1/4 6.40 0.435 11.1 2755 190 11020 760 3.0 75 115
PH704-06 -06 10 3/8 9.65 0.591 15.0 2393 165 9572 660 5.0 125 170
PH704-08 -08 12 1/2 12.83 0.697 17.7 1740 120 6960 480 6.6 165 260

img  Temperature Range : Continuous : -40°C to +100°C
